GCL Geotextile Mat Waterproof Blanket

The GCL (Geosynthetic Clay Liner) geotextile mat water resistant blanket is an progressive fabric designed for quality waterproofing and containment applications. This best composite fabric consists of a geotextile cloth sandwiched between layers of bentonite clay. The geotextile fabric affords power and durability, even as the bentonite clay swells when in contact with water, developing a dense, impermeable barrier.

The material's ability to conform to uneven surfaces and elaborate terrains, coupled with its high-quality chemical resistance, makes it a reliable desire for annoying waterproofing projects.

Contact Now E-Mail Telephone WhatsApp

Product Details

Advantages:

1.Superior Waterproofing Properties: The GCL geotextile mat is designed with a bentonite clay layer that swells when in contact with water, creating a dense, impermeable barrier. This effectively prevents the infiltration of water and contaminants, making positive absolute best best waterproofing performance.

2.Excellent Chemical Resistance: The fabric is resistant to a vast fluctuate of chemicals, alongside with acids, alkalis, and herbal solvents. This makes it splendid for use in a vary of traumatic environments the region publicity to chemical compounds is likely.

3.High Strength and Durability: The geotextile fabric trouble of the GCL mat affords terrific electrical energy and durability. It can stand up to the rigors of installation, as well as long-term publicity to the elements, making certain reliable typical overall performance over time.

4.Ease of Installation: The GCL geotextile mat is hassle-free to install, requiring minimal disruption to the surrounding environment. It can be rolled out and positioned in region quickly and efficiently, decreasing set up time and costs.

5.Conformability: The material is incredibly conformable, in a function to adapt to uneven surfaces and complex terrains. This ensures a continuous, seamless barrier is achieved, even in hard set up conditions.

6.Environmental Friendliness: The GCL geotextile mat is an environmentally satisfactory solution. It is made from non-toxic supplies and can be disposed of safely at the give up of its service life.

7.Cost-Effectiveness: While the preliminary funding in GCL geotextile mats may also additionally be increased than normal waterproofing methods, the most dependable typical overall performance and sturdiness of the cloth regularly lead to minimize common costs over the prolonged term.

geosynthetic clay liner.jpg

Technical Data:

Test ltem	Test Properties	Unit	GCL4	GCL5	GCL5	GCL7	GCL8
Weight		g/㎡	400	500	600	700	800
Film Thickness		Mm		0.25-0.35		0.30-0.50
Mechanical Properties	Break Strength	kN/m	5.0	7.5	10.0	12.0	14.0
	Break Elongation	%	30-100	30-100	30-100	30-100	30-100
	CBR Burst Strength	KN	1.1	1.5	1.9	2.2	2.5
	Tear Resistance	KN	0.15	0.25	0.32	0.40	0.48
	Peel Strength	N/cm	≥6	≥6	≥6	≥6	≥6
Hydrostatic Pressure	Film Thickness	Mm	0.2	0.3	0.4	0.5	0.6
	One cloth one film	Mpa	0.4	0.5.	0.6	0.8	1.0
	Two cloth one film	Mpa	0.5	0.6	0.8	1.0	1.2

geosynthetic clay liner.jpg

Application:

1.Landfill Liners: GCL mats are frequently used as liners in landfills to forestall the infiltration of contaminants into the surrounding soil and groundwater. They supply a continuous, impermeable barrier that efficaciously isolates the waste from the environment.

2.Hazardous Waste Containment: In amenities that deal with hazardous waste, GCL mats are used to create impervious containment areas. They provide most desirable chemical resistance, making sure that the waste is safely contained and does no longer leak into the surrounding environment.

3.Pond and Reservoir Liners: For the development of ponds, reservoirs, and different water bodies, GCL mats furnish an wonderful waterproofing solution. They stop water loss via infiltration and shield the water first-class from contaminants.

4.Canal and Ditch Liners: In irrigation canals, drainage ditches, and different water administration systems, GCL mats are used to forestall leakage and erosion. They make certain that the water flows efficaciously besides inflicting injury to the surrounding soil.

5.Road and Tunnel Construction: In avenue and tunnel projects, GCL mats are frequently employed to water-resistant the foundations and underground structures. They supply a dependable barrier in opposition to groundwater infiltration, defending the structural integrity of the project.

6.Erosion Control: In areas inclined to erosion, GCL mats can be used to stabilize slopes and forestall soil loss. They conform to the contours of the terrain, offering a non-stop overlaying that reduces the affect of erosion.

7.Mining Applications: In mining operations, GCL mats are used to incorporate tailings and forestall the unfold of contaminants. They provide a not pricey answer for developing impervious containment areas that meet environmental regulations.
